RESPONSIBLE AGENCY IGE (Instituto Geografico Nacional de Espana)
RESPONSIBLE FOR METADATA IGE (Instituto Geografico Nacional de Espana)
CURRENT STATION CONFIGURATION tar000esp_20231024.log
STATUS IN EPN included since 15-09-2019
DATA LICENSE CC-BY-4.0
DIGITAL OBJECT IDENTIFIER (DOI) https://doi.org/10.24414/ROB-EUREF-TAR000ESP
LAST AVAILABLE DATA 06-02-2025
LAST RECEIVER LEICA GR25 (07-04-2021 to now)
SET TO TRACK GPS+GLO+GAL
LAST ANTENNA LEIAR20/LEIM (24-10-2023 to now)
INDIVIDUAL CALIBRATION(S) none
DATA ROUTINELY ANALYSED BY ASI, BEK, IGE, WUT
INCLUSION IN OTHER NETWORK(S) EPOS

The RINEX 2 data are no more submitted to the EPN data centres since 02-12-2020.

RINEX V2.11 - GPS+GLO
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 335/2020 N/A
BEV 316/2020 N/A
BKGE 335/2020 N/A
RINEX V3.03 - GPS+GLO+GAL
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 030/2025 75%
BEV 037/2025 100%
BKGE 037/2025 96.43%
Hourly

No recent data available

Hourly
Data centres Online Last data Availability Latency
BEV 038/2025 (E) 100% 100%
BKGE 038/2025 (E) 99.4% 97.62%

Daily and Hourly Latency Plots

Recent RINEX file errors detected by BKG data centre: web page

BKG upload settings to other data centres.

Real-time

TAR000ESP0 :

  • ASI (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL (MSM7)

    2025/02/06 17:18 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL) wrt source table (GPS+GLO)

    2025/02/06 17:18 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (4.11.606) wrt site log (4.11/6.713)

  • BKG (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL (MSM7)

    2025/02/06 14:37 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (4.11.606) wrt site log (4.11/6.713)

  • ROB (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL (MSM7)

    2025/02/06 16:00 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (4.11.606) wrt site log (4.11/6.713)

information above extracted from monitor files - https://epncb.oma.be/pub/station/real_time/

Location

Pictures
