EUREF Permanent GNSS Network

Station Configuration

RESPONSIBLE AGENCY	UWM (University of Warmia and Mazury in Olsztyn)
RESPONSIBLE FOR METADATA	UWM (University of Warmia and Mazury in Olsztyn)
CURRENT STATION CONFIGURATION	lama00pol_20240415.log
STATUS IN EPN	included since 31-12-1995
LAST AVAILABLE DATA	15-04-2024
LAST RECEIVER	LEICA GR50 (17-02-2022 to now)
SET TO TRACK	GPS+GLO+GAL+BDS+QZSS+SBAS
LAST ANTENNA	LEIAR20/LEIM (12-04-2024 to now)
INDIVIDUAL CALIBRATION(S)	none
DATA ROUTINELY ANALYSED BY	BEV, COD, GFZ, MUT, WUT
INCLUSION IN OTHER NETWORK(S)	IGS

Data Provided

The RINEX 2 data are no more submitted to the EPN data centres since 15-03-2022.

No recent data available

Recent RINEX file errors detected by BKG data centre: web page, API (JSON format)

BKG upload settings to other data centres.

LAMA00POL0 :

ASI (broadcaster, registration) - RTCM 3.1 : GPS+GLO
2024/04/15 21:54 RTCM 3.1 : Unexpected constellations in stream (GPS+GLO) wrt site log (GPS+GLO+GAL+BDS+QZSS+SBAS)
2024/04/15 21:54 RTCM 3.1/1033: Incorrect Receiver Firmware Version in stream (4.50.274) wrt site log (4.50/7.710)
2024/04/15 21:54 RTCM 3.1/1006: Incorrect Antenna Height in stream (0.0600 m) wrt site log (0.18488 m)
2024/04/15 21:54 RTCM 3.1/1006: Coordinate difference with ETRS89 ( 0.0532 m) exceeds threshold

BKG (broadcaster, registration) - RTCM 3.1 : GPS+GLO
2024/04/16 19:53 RTCM 3.1 : Unexpected constellations in stream (GPS+GLO) wrt site log (GPS+GLO+GAL+BDS+QZSS+SBAS)
2024/04/16 19:53 RTCM 3.1/1033: Incorrect Receiver Firmware Version in stream (4.50.274) wrt site log (4.50/7.710)
2024/04/16 19:53 RTCM 3.1/1006: Incorrect Antenna Height in stream (0.0600 m) wrt site log (0.18488 m)
2024/04/16 19:53 RTCM 3.1/1006: Coordinate difference with ETRS89 ( 0.0532 m) exceeds threshold

ROB (broadcaster, registration) - RTCM 3.1 : GPS+GLO
2024/04/16 00:52 RTCM 3.1 : Unexpected constellations in stream (GPS+GLO) wrt site log (GPS+GLO+GAL+BDS+QZSS+SBAS)
2024/04/16 00:52 RTCM 3.1/1033: Incorrect Receiver Firmware Version in stream (4.50.274) wrt site log (4.50/7.710)
2024/04/16 00:52 RTCM 3.1/1006: Incorrect Antenna Height in stream (0.0600 m) wrt site log (0.18488 m)
2024/04/16 00:52 RTCM 3.1/1006: Coordinate difference with ETRS89 ( 0.0532 m) exceeds threshold

information above extracted from monitor files - https://epncb.oma.be/pub/station/real_time/

RINEX Data Quality

Daily tracking performances

Monthly snapshots of satellite tracking

Position, Velocity & Time Series

EUREF is providing positions and velocities for the station LAMA00POL
Last ETRF2000 position valid from 322/2007 to 316/2022 expressed at epoch 001/2010
X = 3524523.257 m	Vx = -0.0004 m/y
Y = 1329693.428 m	Vy = -0.0005 m/y
Z = 5129846.164 m	Vz = -0.0008 m/y
