RESPONSIBLE AGENCY ZU (Land Survey Office)
RESPONSIBLE FOR METADATA ZU (Land Survey Office)
CURRENT STATION CONFIGURATION crak00cze_20220818.log
STATUS IN EPN included since 21-03-2010
DATA LICENSE CC-BY-4.0
LAST AVAILABLE DATA 06-02-2025
LAST RECEIVER LEICA GR30 (18-08-2022 to now)
SET TO TRACK GPS+GLO+GAL+BDS+QZSS+SBAS
LAST ANTENNA LEIAR25.R4/LEIT (11-05-2011 to now)
INDIVIDUAL CALIBRATION(S)
  • LEIAR25.R4/LEIT (SN: 10161007) from 2011-05-11 to now :
DATA ROUTINELY ANALYSED BY BEV, IGN, SGO, SUT
INCLUSION IN OTHER NETWORK(S) EPOS

The RINEX 2 data are no more submitted to the EPN data centres since 02-08-2022.

RINEX V2.11 - GPS+GLO
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 213/2022 N/A
BEV 213/2022 N/A
BKGE 213/2022 N/A
RINEX V3.04 - GPS+GLO+GAL+BDS+SBAS
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 030/2025 75%
BEV 037/2025 100%
BKGE 037/2025 100%
Hourly

No recent data available

Hourly
Data centres Online Last data Availability Latency
BEV 038/2025 (D) 100% 97.02%
BKGE 038/2025 (D) 100% 95.83%

Daily and Hourly Latency Plots

Recent RINEX file errors detected by BKG data centre: web page

BKG upload settings to other data centres.

Real-time

CRAK00CZE0 :

  • ASI (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS+QZSS (MSM5)

    2025/02/06 11:42 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS+QZSS) wrt site log (GPS+GLO+GAL+BDS+QZSS+SBAS)

    2025/02/06 11:42 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS+QZSS) wrt source table (GPS+GLO)

    2025/02/06 11:42 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (4.60) wrt site log (4.60/7.811)

  • BKG (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS (MSM5)

    2025/02/06 08:26 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt site log (GPS+GLO+GAL+BDS+QZSS+SBAS)

    2025/02/06 08:26 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt source table (GPS+GLO+GAL+BDS+QZSS)

    2025/02/06 08:26 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (4.60) wrt site log (4.60/7.811)

  • ROB (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS+QZSS (MSM5)

    2025/02/06 09:50 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS+QZSS) wrt site log (GPS+GLO+GAL+BDS+QZSS+SBAS)

    2025/02/06 09:50 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (4.60) wrt site log (4.60/7.811)

information above extracted from monitor files - https://epncb.oma.be/pub/station/real_time/

Location

Pictures
