EUREF Permanent GNSS Network

Station Configuration

RESPONSIBLE AGENCY	ELB (Estonian Land Board)
RESPONSIBLE FOR METADATA	ELB (Estonian Land Board)
CURRENT STATION CONFIGURATION	tor300est_20230726.log
STATUS IN EPN	included since 10-09-2023
DATA LICENSE	CC-BY-4.0
LAST AVAILABLE DATA	18-05-2024
LAST RECEIVER	LEICA GR25 (26-07-2023 to now)
SET TO TRACK	GPS+GLO+GAL
LAST ANTENNA	LEIAR25.R4/LEIT (07-10-2022 to now)
INDIVIDUAL CALIBRATION(S)	none
DATA ROUTINELY ANALYSED BY	LPT, NKG, WUT
INCLUSION IN OTHER NETWORK(S)	EPOS

Data Provided

The RINEX 2 data are no more submitted to the EPN data centres since 19-05-2023.

No recent data available

No recent data available

Recent RINEX file errors detected by BKG data centre: web page, API (JSON format)

BKG upload settings to other data centres.

TOR300EST0 :

ASI (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL (MSM5)
2024/05/19 01:59 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (4.70) wrt site log (4.70/6.525)
2024/05/19 01:59 RTCM 3.2/1006: Incorrect Antenna Height in stream (0.0000 m) wrt site log (0.15897 m)

BKG (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL (MSM5)
2024/05/19 00:26 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (4.70) wrt site log (4.70/6.525)
2024/05/19 00:26 RTCM 3.2/1006: Incorrect Antenna Height in stream (0.0000 m) wrt site log (0.15897 m)

ROB (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL (MSM5)
2024/05/19 05:22 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (4.70) wrt site log (4.70/6.525)
2024/05/19 05:22 RTCM 3.2/1006: Incorrect Antenna Height in stream (0.0000 m) wrt site log (0.15897 m)

information above extracted from monitor files - https://epncb.oma.be/pub/station/real_time/

RINEX Data Quality
